The cooling water of the medium frequency furnace is a topic that cannot be separated from the heating of the medium frequency furnace. This cooling water is to reduce the heat generated during the working process of the intermediate frequency furnace and ensure the normal operation of the intermediate frequency furnace. Its role is to take away the heat generated inside the intermediate frequency furnace to ensure its stable operation. If it is not cooled in time, it may affect the heating power of the intermediate frequency furnace, and even burn the equipment, so the role of the cooling water of the intermediate frequency furnace is very important.
Ⅰ Medium frequency furnace water temperature requirements: the inlet temperature of the cooling water of the medium frequency furnace should be kept within a certain range, usually required to be 5~30 ° C, the outlet temperature should be controlled at 30~40 ° C, and the outlet temperature should not exceed 55 ° C. The water temperature is too low and condensation may occur, while the water temperature is too high and the cooling ability may be lost. Therefore, maintaining the appropriate cooling water temperature of the intermediate frequency furnace is crucial to the normal operation of the equipment.
Ⅱ The water quality of the cooling water of the intermediate frequency furnace also needs to meet certain requirements, including pH value, hardness, resistivity, suspended solids, alkalinity, conductivity, chloride ions, sulfuric acid ions, total iron and soluble SiO2 and other indicators. The specific requirements of these indicators may vary according to different equipment and application scenarios, but it is usually necessary to ensure that the water quality is clean and stable to prevent problems such as scale and corrosion. Intermediate frequency furnace cooling water requirements of the specific indicators are as follows:
- The one-time storage water of the cooling water internal circulation system of the intermediate frequency furnace is about 6m3, and the daily consumption is about 6kg/ day. Artificial hydration.
- if frequency furnace cooling water pH value: 7 ~ 9
- if frequency furnace cooling water chloride content: < 20ppm
- intermediate frequency furnace cooling water nitrate content: < 10ppm
- sulfate content: < 100ppm
- intermediate frequency furnace cooling water solid: < 250ppm
- intermediate frequency furnace cooling water hardness: < 250ppm calcium carbonate 8, conductivity: < 50us/cm
Ⅲ Intermediate frequency furnace cooling water and pressure requirements: intermediate frequency furnace cooling water flow and pressure also need to meet certain requirements to ensure the cooling effect. The specific water and pressure requirements depend on the model and power of the Seishan electric furnace.
Ⅳ In order to ensure the normal operation of cooling water of the intermediate frequency furnace, it is also necessary to carry out regular maintenance and management of cooling water of the intermediate frequency furnace, including cleaning cooling pipes, replacing cooling water, checking the operating status of pumps and water pipes and other equipment.
Ⅶ Intermediate frequency furnace cooling water requirements include: no scaling, no blockage, no corrosion, no evaporation, no conduction. The circulating water of the medium frequency furnace needs to pass through the small heat exchange pipe inside the thyristor, which, through heat conduction, transfers the heat generated during the operation of the thyristor to the circulating water, and then evaporates and cools through the spray water of the closed cooling tower, or evaporates through the circulating water itself of the open cooling tower, and transfers the heat energy to the outdoor atmospheric environment to complete the purpose of heat energy conversion.
